Nuts
LOCK NUT NYLON UNC ZINC 1"-8 GR 8
X8LN18
- Hex nut with a nylon-filled collar at its back end.
- When a screw reaches the collar, the threads and nylon engage for a tight, frictional fit.
- Restricts movement of the screw when it is subjected to vibration.
- Designed to be used in structural application with Grade 8 cap screws or bolts.
- Applications include engines, turbines, hydraulic cylinders, railroads and aerospace.
- Nylon inserts nuts are not designed to be used at temperatures over 250° F.
- Made from heat treated steel.
- Proof load: 150,000 psi.
- Size: 1"-8.
- Yellow zinc plated.
$34.81
$3.4812
$3.4812
LOCK NUT NYLON UNF ZINC 3/4"-16 GR 8
X8LN3416
- Hex nut with a nylon-filled collar at its back end
- When a screw reaches the collar, the threads and nylon engage for a tight, frictional fit
- Restricts movement of the screw when it is subjected to vibration.
- Designed to be used in structural application with Grade 8 cap screws or bolts
- Applications include engines, turbines, hydraulic cylinders, railroads and aerospace
- Nylon inserts nuts are not designed to be used at temperatures over 250° F
- Made from heat treated steel
- Proof load: 150,000 psi
- Size: 3/4″-16
- Yellow zinc plated
$116.33
$4.653
$4.653
LOCK NUT NYLON UNC ZINC 3/8"-16 GR 8
X8LN3816
- Hex nut with a nylon-filled collar at its back end.
- When a screw reaches the collar, the threads and nylon engage for a tight, frictional fit.
- Restricts movement of the screw when it is subjected to vibration.
- Designed to be used in structural application with Grade 8 cap screws or bolts.
- Applications include engines, turbines, hydraulic cylinders, railroads and aerospace.
- Nylon inserts nuts are not designed to be used at temperatures over 250° F.
- Made from heat treated steel.
- Proof load: 150,000 psi.
- Size: 3/8"-16.
- Yellow zinc plated.
$55.44
$0.5544
$0.5544
LOCK NUT NYLON UNC ZINC 5/16"-18 GR 8
X8LN5618
- Hex nut with a nylon-filled collar at its back end.
- When a screw reaches the collar, the threads and nylon engage for a tight, frictional fit.
- Restricts movement of the screw when it is subjected to vibration.
- Designed to be used in structural application with Grade 8 cap screws or bolts.
- Applications include engines, turbines, hydraulic cylinders, railroads and aerospace.
- Nylon inserts nuts are not designed to be used at temperatures over 250° F.
- Made from heat treated steel.
- Proof load: 150,000 psi.
- Size: 5/16"-18.
- Yellow zinc plated.
$33.96
$0.3396
$0.3396
LOCK NUT NYLON UNC ZINC 5/8"-11 GR 8
X8LN5811
- Hex nut with a nylon-filled collar at its back end.
- When a screw reaches the collar, the threads and nylon engage for a tight, frictional fit.
- Restricts movement of the screw when it is subjected to vibration.
- Designed to be used in structural application with Grade 8 cap screws or bolts.
- Applications include engines, turbines, hydraulic cylinders, railroads and aerospace.
- Nylon inserts nuts are not designed to be used at temperatures over 250° F.
- Made from heat treated steel.
- Proof load: 150,000 psi.
- Size: 5/8"-11.
- Yellow zinc plated.
$32.99
$1.3195
$1.3195
LOCK NUT NYLON UNC ZINC 7/16"-14 GR 8
X8LN7614
- Hex nut with a nylon-filled collar at its back end.
- When a screw reaches the collar, the threads and nylon engage for a tight, frictional fit.
- Restricts movement of the screw when it is subjected to vibration.
- Designed to be used in structural application with Grade 8 cap screws or bolts.
- Applications include engines, turbines, hydraulic cylinders, railroads and aerospace.
- Nylon inserts nuts are not designed to be used at temperatures over 250° F.
- Made from heat treated steel.
- Proof load: 150,000 psi.
- Size: 7/16"-14.
- Yellow zinc plated.
$31.16
$0.6232
$0.6232
LOCK NUT NYLON UNC ZINC 7/8"-9 GR 8
X8LN789
- Hex nut with a nylon-filled collar at its back end.
- When a screw reaches the collar, the threads and nylon engage for a tight, frictional fit.
- Restricts movement of the screw when it is subjected to vibration.
- Designed to be used in structural application with Grade 8 cap screws or bolts.
- Applications include engines, turbines, hydraulic cylinders, railroads and aerospace.
- Nylon inserts nuts are not designed to be used at temperatures over 250° F.
- Made from heat treated steel.
- Proof load: 150,000 psi.
- Size: 7/8"-9.
- Yellow zinc plated.
$38.70
$3.87
$3.87
LOCK NUT NYLON UNF ZINC 7/8"-14 GR 8
X8LN7814
- Hex nut with a nylon-filled collar at its back end
- When a screw reaches the collar, the threads and nylon engage for a tight, frictional fit
- Restricts movement of the screw when it is subjected to vibration.
- Designed to be used in structural application with Grade 8 cap screws or bolts
- Applications include engines, turbines, hydraulic cylinders, railroads and aerospace
- Nylon inserts nuts are not designed to be used at temperatures over 250° F
- Made from heat treated steel
- Proof load: 150,000 psi
- Size: 7/8"-14
- Yellow zinc plated
$36.95
$3.6954
$3.6954
LOCK NUT NYLON UNC ZINC 9/16"-12 GR 8
X8LN9612
- Hex nut with a nylon-filled collar at its back end
- When a screw reaches the collar, the threads and nylon engage for a tight, frictional fit
- Restricts movement of the screw when it is subjected to vibration.
- Designed to be used in structural application with Grade 8 cap screws or bolts
- Applications include engines, turbines, hydraulic cylinders, railroads and aerospace
- Nylon inserts nuts are not designed to be used at temperatures over 250° F
- Made from heat treated steel
- Proof load: 150,000 psi
- Size: 9/16"-12
- Yellow zinc plated
$68.42
$1.3683
$1.3683
LOCK NUT STOVER ZINC M10-1.50
X8SLN10M
- Stover lock nuts, also called Grade C automation lock nuts.
- All metal, one-piece hex nut which derives it prevailing torque characteristics from controlled distortion of it top threads from their normal helical form to a more elliptical shape.
- Can withstand temperatures up to 450°s F.
- Can withstand severe vibration and shock loads.
- Frequently used in farm machinery, plus the automotive and related metalworking industries.
$35.44
$0.7088
$0.7088
LOCK NUT STOVER PLAIN 1/2"-13 FLANGED
X8SLN1213F
- Stover lock nuts, also called Grade C automation lock nuts.
- All metal, one-piece hex nut which derives it prevailing torque characteristics from controlled distortion of it top threads from their normal helical form to a more elliptical shape.
- Can withstand temperatures up to 450°s F.
- Can withstand severe vibration and shock loads.
- Has a flange on the bottom side of the nut for a wider bearing surface.
- Frequently used in farm machinery, plus the automotive and related metalworking industries.
- Proof load 150,000 psi.
- Plain finish.
- Size: 1/2"-13.
$141.05
$2.821
$2.821
LOCK NUT STOVER HEX FLANGE GR G ALL METAL 1/4"-20
X8SLN1420F
- Stover lock nuts, also called Grade C automation lock nuts.
- All metal, one-piece hex nut which derives it prevailing torque characteristics from controlled distortion of it top threads from their normal helical form to a more elliptical shape.
- Can withstand temperatures up to 450°s F.
- Can withstand severe vibration and shock loads.
- Has a flange on the bottom side of the nut for a wider bearing surface.
- Frequently used in farm machinery, plus the automotive and related metalworking industries.
- Proof load 150,000 psi.
- Plain finish.
- Size: 1/4"-20.
$42.70
$0.427
$0.427
LOCK NUT STOVER FLANGE, GR G, 1-8
X8SLN18F
- Stover lock nuts, also called Grade C automation lock nuts.
- All metal, one-piece hex nut which derives it prevailing torque characteristics from controlled distortion of it top threads from their normal helical form to a more elliptical shape.
- Can withstand temperatures up to 450°s F.
- Can withstand severe vibration and shock loads.
- Has a flange on the bottom side of the nut for a wider bearing surface.
- Frequently used in farm machinery, plus the automotive and related metalworking industries.
- Proof load 150,000 psi.
- Plain finish.
- Size: 1"-18.
$91.29
$9.1285
$9.1285
LOCK NUT STOVER ZINC 3/4"-10 FLANGED
X8SLN3410F
- Stover lock nuts, also called Grade C automation lock nuts.
- All metal, one-piece hex nut which derives it prevailing torque characteristics from controlled distortion of it top threads from their normal helical form to a more elliptical shape.
- Can withstand temperatures up to 450°s F.
- Can withstand severe vibration and shock loads.
- Has a flange on the bottom side of the nut for a wider bearing surface.
- Frequently used in farm machinery, plus the automotive and related metalworking industries.
- Proof load 150,000 psi.
- Plain finish.
- Size: 3/4"-10.
$83.61
$3.3444
$3.3444
LOCK NUT STOVER ZINC 5/16"-18 FLANGED
X8SLN5618F
- Stover lock nuts, also called Grade C automation lock nuts.
- All metal, one-piece hex nut which derives it prevailing torque characteristics from controlled distortion of it top threads from their normal helical form to a more elliptical shape.
- Can withstand temperatures up to 450°s F.
- Can withstand severe vibration and shock loads.
- Has a flange on the bottom side of the nut for a wider bearing surface.
- Frequently used in farm machinery, plus the automotive and related metalworking industries.
- Proof load 150,000 psi.
- Plain finish.
- Size: 5/16"-18.
$42.70
$0.854
$0.854
