Washers
LOCK WASHER SPLIT STAINLESS 5/16"
LW56SS
- A coiled, hardened split circular washer with a slightly trapezoidal wire section.
- Applies greater bolt tension per unit of applied torque.
- Provides a hardened bearing surface and more uniform load distribution.
- Stainless Steel.
- Resists loosening caused by vibration and corrosion.
- For use with stainless nuts and screws of a similar stainless alloy.
- Rockwell Hardness: C35-43
- Inside Diameter: Min .314 Max .322
- Outside Diameter: 0.583
$26.64
$0.2664
$0.2664
LOCK WASHER SPLIT METRIC ZINC M8
LW8M
- A coiled, hardened split circular washer with a slightly trapezoidal wire section.
- Applies greater bolt tension per unit of applied torque.
- Provides a hardened bearing surface and more uniform load distribution.
- Steel, zinc plated.
- Resists loosening caused by vibration and corrosion.
- For use with metric bolts and screws.
- Rockwell Hardness: C44-51
- Inside Diameter: Min 8.1 Max 8.5
- Outside Diameter: 14.8
$15.00
$0.15
$0.15
FLAT WASHER USS STAINLESS #8
FW8SS
- Used to improve stress distribution, and to span large holes.
- USS PATTERN.
- Used where parts are subject to corrosion.
- Made from 18-8 stainless steel.
$10.00
$0.10
$0.10
LOCK WASHER SPLIT USS ZINC 1/4" GR 5
LW14
- A coiled, hardened split circular washer with a slightly trapezoidal wire section.
- Applies greater bolt tension per unit of applied torque.
- Provides a hardened bearing surface and more uniform load distribution.
- Resists loosening caused by vibration and corrosion.
- Designed for use with grade 5 bolts.
- Rockwell Hardness: C38-46
- Inside Diameter: Min .252 Max .260
- Outside Diameter: 0.487
$22.35
$0.2235
$0.2235
FLAT WASHER SAE ZINC #6
SFW6
- Used to improve stress distribution, and to span large holes.
- SAE PATTERN.
- Made from low carbon steel, zinc plated.
- Outside Diameter: 3/8"
- Inside Diameter: 5/32"
$19.20
$0.192
$0.192
FLAT WASHER METRIC ZINC M10 CL10
XFW10M10
- Used to improve stress distribution, and to span large holes.
- For use with class 8.8 and 10.9 screws and studs.
- Steel, zinc plated.
- Inside Diameter: Min 10.5 Max 10.77
- Outside Diameter: Min 19.48 Max 20
$47.92
$0.4792
$0.4792
FLAT WASHER METRIC ZINC M12 CL10
XFW12M10
- Used to improve stress distribution, and to span large holes.
- For use with class 8.8 and 10.9 screws and studs.
- Steel, zinc plated.
- Inside Diameter: Min 13 Max 13.27
- Outside Diameter: Min 23.48 Max 24
$97.02
$0.9702
$0.9702
FLAT WASHER USS ZINC 5/8" THRU HARDENED
8FW58
- Used to improve stress distribution, and to span large holes.
- USS PATTERN.
- Made from heat treated thru-hardened steel, zinc yellow.
- Outside Diameter: 1-3/4"
- Inside Diameter: 11/16"
$35.18
$0.7035
$0.7035
FLAT WASHER USS ZINC 9/16" THRU HARDENED
8FW96
- Used to improve stress distribution, and to span large holes.
- USS PATTERN.
- Made from heat treated thru-hardened steel, zinc yellow.
- Outside Diameter: 1-1/2"
- Inside Diameter: 5/8"
$32.12
$0.6424
$0.6424
LOCK WASHER SPLIT USS ZINC 1/4" HIGH ALLOY
8LW14
- A coiled, hardened split circular washer with a slightly trapezoidal wire section.
- Applies greater bolt tension per unit of applied torque.
- Provides a hardened bearing surface and more uniform load distribution.
- Steel, yellow zinc plated.
- Resists loosening caused by vibration and corrosion.
- For use with grade 8 bolts.
- Rockwell Hardness: C38-46
- Inside Diameter: Min .252 Max .260
- Outside Diameter: 0.487
$25.20
$0.252
$0.252
LOCK WASHER SPLIT USS ZINC 3/8" HIGH ALLOY
8LW38
- A coiled, hardened split circular washer with a slightly trapezoidal wire section.
- Applies greater bolt tension per unit of applied torque.
- Provides a hardened bearing surface and more uniform load distribution.
- Steel, yellow zinc plated.
- Resists loosening caused by vibration and corrosion.
- For use with grade 8 bolts.
- Rockwell Hardness: C38-46
- Inside Diameter: Min .377 Max .385
- Outside Diameter: 0.68
$22.95
$0.2295
$0.2295
FLAT WASHER SAE ZINC 3/4" THRU HARDENED
8SFW34
- Used to improve stress distribution, and to span large holes.
- Yellow zinc plated.
- Made from heat treated thru-hardened steel.
- SAE PATTERN
- Outside Diameter: 1-1/2"
- Inside Diameter: 13/16"
$13.82
$0.5528
$0.5528
FLAT WASHER SAE ZINC 5/16" THRU HARDENED
8SFW56
- Used to improve stress distribution, and to span large holes.
- Yellow zinc plated.
- Made from heat treated thru-hardened steel.
- SAE PATTERN
- Outside Diameter: 11/16"
- Inside Diameter: 11/32"
$19.60
$0.196
$0.196
FLAT WASHER SAE ZINC 5/8" THRU HARDENED
8SFW58
- Used to improve stress distribution, and to span large holes.
- Yellow zinc plated.
- Made from heat treated thru-hardened steel.
- SAE PATTERN
- Outside Diameter: 1-5/16"
- Inside Diameter: 21/32"
$23.30
$0.466
$0.466
FLAT WASHER METRIC ZINC M12
FW12M
- Used to improve stress distribution, and to span large holes.
- Din 125A
- Made from low carbon steel, zinc plated.
- Inside Diameter: Min 13 Max 13.27
- Outside Diameter: Min 23.48 Max 24
$27.90
$0.279
$0.279
FLAT WASHER USS STAINLESS 1/4"
FW14SS
- Used to improve stress distribution, and to span large holes.
- USS PATTERN.
- Used where parts are subject to corrosion.
- Made from 18-8 stainless steel.
- Outside Diameter: 3/4"
- Inside Diameter: 5/16"
$18.15
$0.1815
$0.1815
FLAT WASHER METRIC ZINC M6
FW6M
- Used to improve stress distribution, and to span large holes.
- Din 125A
- Made from low carbon steel, zinc plated.
- Inside Diameter: Min 6.4 Max 6.62
- Outside Diameter: Min 11.57 Max 12
$10.80
$0.108
$0.108
FLAT WASHER USS ZINC 5/16"
FW56
- Used to improve stress distribution, and to span large holes.
- USS PATTERN.
- Made from low carbon steel, zinc plated.
- Outside Diameter: 7/8"
- Inside Diameter: 3/8"
$23.85
$0.2385
$0.2385
FLAT WASHER METRIC ZINC M8
FW8M
- Used to improve stress distribution, and to span large holes.
- Din 125A
- Made from low carbon steel, zinc plated.
- Inside Diameter: Min 8.4 Max 8.62
- Outside Diameter: Min 15.57 Max 16
$17.40
$0.174
$0.174
FLAT WASHER USS ZINC 1/4" THRU HARDENED
8FW14
- Used to improve stress distribution, and to span large holes.
- USS PATTERN.
- Made from heat treated thru-hardened steel, zinc yellow.
- Outside Diameter: 3/4"
- Inside Diameter: 5/16"
$23.55
$0.2355
$0.2355
FLAT WASHER USS ZINC 3/4" THRU HARDENED
8FW34
- Used to improve stress distribution, and to span large holes.
- USS PATTERN.
- Made from heat treated thru-hardened steel, zinc yellow.
- Outside Diameter: 2"
- Inside Diameter: 13/16"
$24.01
$0.9604
$0.9604
FLAT WASHER SAE ZINC 1/2" THRU HARDENED
8SFW50
- Used to improve stress distribution, and to span large holes.
- Yellow zinc plated.
- Made from heat treated thru-hardened steel.
- SAE PATTERN
- Outside Diameter: 1-1/16"
- Inside Diameter: 17/32"
$29.76
$0.2976
$0.2976
LOCK WASHER SPLIT USS ZINC 1/2" HIGH ALLOY
8LW50
- A coiled, hardened split circular washer with a slightly trapezoidal wire section.
- Applies greater bolt tension per unit of applied torque.
- Provides a hardened bearing surface and more uniform load distribution.
- Steel, yellow zinc plated.
- Resists loosening caused by vibration and corrosion.
- For use with grade 8 bolts.
- Rockwell Hardness: C38-46
- Inside Diameter: Min .502 Max .512
- Outside Diameter: 0.869
$35.28
$0.3528
$0.3528
FLAT WASHER USS ZINC 3/8"
FW38
- Used to improve stress distribution, and to span large holes.
- USS PATTERN.
- Made from low carbon steel, zinc plated.
- Outside Diameter: 1"
- Inside Diameter: 7/16"
$29.25
$0.2925
$0.2925
FLAT WASHER USS ZINC 7/16"
FW76
- Used to improve stress distribution, and to span large holes.
- USS PATTERN.
- Made from low carbon steel, zinc plated.
- Outside Diameter: 1-1/4"
- Inside Diameter: 1/2"
$40.40
$0.404
$0.404
