FEMALE JIC 37° SWIVEL 9/16"-18 THREAD, 1/2" HOSE

  • Parker 43 series fittings are a permanent (crimp) style fitting.
  • Permits quick assembly with the Parker family of Parkrimp crimpers.
  • Assembly of No-Skive hose and fittings does not require removal of the outer cover of the hose.
  • 43 series fittings are made from Chromium-6 free plated steel.
  • These fittings are used with Parker hydraulic braided, light spiral, specialty, suction and return hoses.
  • Female JIC 37° swivel
  • For use with 1/2" hose.
  • 9/16"-18 thread fitting connection.
  • Do not assemble a Parker fitting on a Parker hose that is not specifically listed by Parker for that fitting, or assemble a Parker fitting on another manufacturer's hose.
  • To ensure proper function and safety, you should only use Parker fittings with Parker hose on an approved Parker crimper for the recommended sizes and pressures.
    Part #: X10643-6-8
    Availability:
    Special Order - 7 to 10 day lead time
    Price: $35.6625
    i h h
    The Female JIC 37 swivel fitting features a 9/16"-18 thread and is designed for use with 1/2" hoses. This elbow-shaped fitting allows for flexible installation in tight spaces. Constructed from Chromium-6 free plated steel, it ensures durability and corrosion resistance. Ideal for use in hydraulic applications, this fitting facilitates a quick assembly process with Parker's crimping systems, eliminating the need to remove the hose's outer cover during installation.
    Products specifications
    Gender Female, Female
    Shape Elbow, Straight
    Inside Diameter 1/2", 1/2"
    Degree 37°, 37
    Compatible Fittings 43 Series, 43 Series
    Thread Size 9/16"-18, 9/16"-18
    Port Connection 3/8", 3/8"
    Material Steel, Steel
    Style Swivel, Swivel
    Type JIC 37°, JIC 37
