Bolts
FRAME BOLT FLANGE HD, NON-SERRATED, UNC BLACK 5/8"-11 X 2-1/2", GR 8
X58X212CFL8
- Made from high alloy steel.
- One piece hex washer head bolt with a flat bearing surface.
- For use on truck frames.
- Flange eliminates washers and helps compensate for a misaligned hole.
- Plain black finish.
- Tensile strength: 150,000 psi minimum.
- Unified screw threads: UNC.
- Diameter: 5/8"-11.
- Length: 2-1/2".
$155.73
$6.2292
$6.2292
FRAME BOLT FLANGE HD, NON-SERRATED, UNC ZINC 5/8"-11 X 2-1/2" GR 8
X58X212CFL8Z
- Made from high alloy steel.
- One piece hex washer head bolt with a flat bearing surface.
- For use on truck frames.
- Flange eliminates washers and helps compensate for a misaligned hole.
- Zinc finish.
$187.91
$7.5164
$7.5164
FRAME BOLT FLANGE HD, NON-SERRATED, UNC BLACK 5/8"-11 X 2", GR 8
X58X2CFL8
- Made from high alloy steel.
- One piece hex washer head bolt with a flat bearing surface.
- For use on truck frames.
- Flange eliminates washers and helps compensate for a misaligned hole.
- Plain black finish.
- Tensile strength: 150,000 psi minimum.
- Unified screw threads: UNC.
- Diameter: 5/8"-11.
- Length: 2".
$110.60
$4.4238
$4.4238
FRAME BOLT FLANGE HD, NON-SERRATED, UNC ZINC 5/8"-11 X 2" GR 8
X58X2CFL8Z
- Made from high alloy steel.
- One piece hex washer head bolt with a flat bearing surface.
- For use on truck frames.
- Flange eliminates washers and helps compensate for a misaligned hole.
- Zinc finish.
$218.54
$8.7416
$8.7416
FRAME BOLT FLANGE HD, NON-SERRATED, UNC BLACK 5/8"-11 X 3" GR8
X58X3CFL8
- Made from high alloy steel.
- One piece hex washer head bolt with a flat bearing surface.
- For use on truck frames.
- Flange eliminates washers and helps compensate for a misaligned hole.
- Plain black finish.
- Tensile strength: 150,000 psi minimum.
- Unified screw threads: UNC.
- Diameter: 5/8"-11.
- Length: 3".
$195.70
$7.828
$7.828
HEX CAP SCREW BOLT 5/8-11" X 8" GR 8 ZINC
X58X8C8
- Made from medium carbon alloy steel.
- Heat treated.
- Tensile strength: 150,000 psi. minimum.
- Yellow zinc plated.
- Unified screw threads :UNC.
$74.41
$7.4412
$7.4412
HEX CAP SCREW BOLT METRIC ZINC M5-0.80 X 16, CL 10.9
X5X16M10.9
- Hex head cap screw with metric thread pitch made from medium carbon alloy steel.
- Heat treated.
- Tensile strength: 1040 Newtons/mm² minimum.
- Zinc plated.
- Metric coarse threads.
- Diameter: M5-.80.
- Length: 16 mm.
- Class 10.9
$21.84
$0.2184
$0.2184
MACHINE SCREW PHIL PAN HD #6-32 X 1/2" STAINLESS
X632X12PSS
- A straight shank fastener with external threads designed to go through a hole or nut that is pre-tapped to form a mating thread for the screw.
- Machine screws form a fastening superior in strength to spaced thread screws.
- Stainless steel machine screws are used in applications which require general atmospheric corrosion resistance.
- Used in food processing machinery and refrigeration equipment.
- Stainless is also superior to steel in withstanding some elevation in application operating temperature while maintaining its strength.
- Made from 18-8 stainless
- Pan head Phillips.
- 6-32 diameter.
- Length of 1/2".
$25.05
$0.2505
$0.2505
SOCKET HEAD CAPSCREW UNC PLAIN #6-32 X 1/2"
X632X12SHC
- Made from alloy steel.
- Cylindrical head with a flat chamfered top surface.
- Knurled cylindrical sides and hexagonal recess.
- Ideal for precision assembly work with close tolerances, and applications needing a well tooled appearance.
- Supplies greater tensile strength than equivalent sizes of grade 5 and grade 8 hex cap screws while requiring less surface area or counterbore since the fastener is internally wrenched.
- Plain black finish.
- Diameter: #6-32
- Length: 1/2"
$21.52
$0.2152
$0.2152
BUTTON HD SOCKET CAPSCREW UNC STAINLESS #6-32 X 1/4"
X632X14BHCS
- Made from stainless steel.
- The dome shaped head is wider and has a lower profile than a socket cap screw.
- Knurled cylindrical sides and hexagonal recess.
- Ideal for precision assembly work with close tolerances, and applications needing a well tooled appearance.
- Supplies greater tensile strength than equivalent sizes of grade 5 and grade 8 hex cap screws while requiring less surface area or counterbore since the fastener is internally wrenched.
$10.80
$0.108
$0.108
SOCKET HEAD CAPSCREW UNC PLAIN #6-32 X 1/4"
X632X14SHC
- Made from alloy steel.
- Cylindrical head with a flat chamfered top surface.
- Knurled cylindrical sides and hexagonal recess.
- Ideal for precision assembly work with close tolerances, and applications needing a well tooled appearance.
- Supplies greater tensile strength than equivalent sizes of grade 5 and grade 8 hex cap screws while requiring less surface area or counterbore since the fastener is internally wrenched.
- Plain black finish.
- Diameter: #6-32
- Length: 1/4"
$21.28
$0.2128
$0.2128
MACHINE SCREW PHIL PAN HD #6-32 X 1" STAINLESS
X632X1PSS
- A straight shank fastener with external threads designed to go through a hole or nut that is pre-tapped to form a mating thread for the screw.
- Machine screws form a fastening superior in strength to spaced thread screws.
- Stainless steel machine screws are used in applications which require general atmospheric corrosion resistance.
- Used in food processing machinery and refrigeration equipment.
- Stainless is also superior to steel in withstanding some elevation in application operating temperature while maintaining its strength.
- Made from 18-8 stainless
- Pan head Phillips.
- 6-32 diameter.
- Length of 1".
$28.68
$0.2868
$0.2868
SOCKET HEAD CAPSCREW UNC PLAIN #6-32 X 3/4"
X632X34SHC
- Made from alloy steel.
- Cylindrical head with a flat chamfered top surface.
- Knurled cylindrical sides and hexagonal recess.
- Ideal for precision assembly work with close tolerances, and applications needing a well tooled appearance.
- Supplies greater tensile strength than equivalent sizes of grade 5 and grade 8 hex cap screws while requiring less surface area or counterbore since the fastener is internally wrenched.
- Plain black finish.
- Diameter: #6-32
- Length: 3/4"
$21.07
$0.2107
$0.2107
MACHINE SCREW PHIL PAN HD #6-32 X 3/8" STAINLESS
X632X38PSS
- A straight shank fastener with external threads designed to go through a hole or nut that is pre-tapped to form a mating thread for the screw.
- Machine screws form a fastening superior in strength to spaced thread screws.
- Stainless steel machine screws are used in applications which require general atmospheric corrosion resistance.
- Used in food processing machinery and refrigeration equipment.
- Stainless is also superior to steel in withstanding some elevation in application operating temperature while maintaining its strength.
- Made from 18-8 stainless
- Pan head Phillips.
- 6-32 diameter.
- Length of 3/8".
$18.80
$0.188
$0.188
SOCKET HEAD CAPSCREW UNC PLAIN #6-32 X 3/8"
X632X38SHC
- Made from alloy steel.
- Cylindrical head with a flat chamfered top surface.
- Knurled cylindrical sides and hexagonal recess.
- Ideal for precision assembly work with close tolerances, and applications needing a well tooled appearance.
- Supplies greater tensile strength than equivalent sizes of grade 5 and grade 8 hex cap screws while requiring less surface area or counterbore since the fastener is internally wrenched.
- Plain black finish.
- Diameter: #6-32
- Length: 3/8"
$21.44
$0.2144
$0.2144
