Bolts
HEX CAP SCREW BOLT UNC ZINC 3/8"-16 X 6", GR 5
38X6C
- Made from medium carbon steel.
- Heat treated.
- Tensile strength: 120,000 psi. minimum.
- Zinc plated.
- Unified screw threads :UNC.
- Diameter: 3/8"-16.
- Length: 6".
$61.52
$1.2303
$1.2303
HEX CAP SCREW BOLT UNF ZINC 3/8"-24 X 6", GR 5
38X6F
- Made from medium carbon steel.
- Heat treated.
- Tensile strength: 120,000 psi. minimum.
- Zinc plated.
- Unified screw threads :UNF.
- Diameter: 3/8"-24.
- Length: 6".
$124.20
$2.484
$2.484
HEX CAP SCREW BOLT UNC ZINC 3/8"-16 X 6", GR 8
38X6C8
- Made from medium carbon alloy steel.
- Heat treated.
- Tensile strength: 150,000 psi. minimum.
- Yellow zinc plated.
- Unified screw threads :UNC.
- Diameter: 3/8"-16.
- Length: 6".
$115.00
$2.30
$2.30
HEX CAP SCREW BOLT UNF ZINC 3/8"-24 X 6", GR 8
38X6F8
- Made from medium carbon alloy steel.
- Heat treated.
- Tensile strength: 150,000 psi. minimum.
- Yellow zinc plated.
- Unified screw threads :UNF.
- Diameter: 3/8"-24.
- Length: 6".
$144.21
$2.8841
$2.8841
HEX CAP SCREW BOLT METRIC ZINC M4-.70 X 12, CL 8.8
4X12M
- Hex head cap screw with metric thread pitch made from medium carbon steel.
- Heat treated.
- Tensile strength: 800 Newtons/mm² minimum.
- Zinc plated.
- Metric coarse threads.
- Diameter: M4-.70.
- Length: 12 mm.
$16.10
$0.161
$0.161
HEX CAP SCREW BOLT METRIC ZINC M4-.70 X 20, CL 8.8
4X20M
- Hex head cap screw with metric thread pitch made from medium carbon steel.
- Heat treated.
- Tensile strength: 800 Newtons/mm² minimum.
- Zinc plated.
- Metric coarse threads.
- Diameter: M4-.70.
- Length: 20 mm.
$23.20
$0.232
$0.232
HEX CAP SCREW BOLT METRIC ZINC M4-.70 X 25, CL 8.8
4X25M
- Hex head cap screw with metric thread pitch made from medium carbon steel.
- Heat treated.
- Tensile strength: 800 Newtons/mm² minimum.
- Zinc plated.
- Metric coarse threads.
- Diameter: M4-.70.
- Length: 25 mm.
$23.84
$0.2384
$0.2384
HEX CAP SCREW UNC STAINLESS 5/16"-18 X 1-1/4"
56114CSS
- Grade 18-8 stainless steel hex cap screws.
- Used in products that require general atmospheric corrosion resistance such as chemical and food processing equipment and marine applications.
- Tensile strength: 100,000 psi. minimum.
- Unified screw threads :UNC.
- Diameter: 5/16"-18.
- Length: 1-1/4".
$64.30
$0.643
$0.643
HEX CAP SCREW UNC STAINLESS 5/16"-18 X 1"
561CSS
- Grade 18-8 stainless steel hex cap screws.
- Used in products that require general atmospheric corrosion resistance such as chemical and food processing equipment and marine applications.
- Tensile strength: 100,000 psi. minimum.
- Unified screw threads :UNC.
- Diameter: 5/16"-18.
- Length: 1".
$44.11
$0.4411
$0.4411
HEX CAP SCREW UNC STAINLESS 5/16"-18 X 2-1/2"
56212CSS
- Grade 18-8 stainless steel hex cap screws.
- Used in products that require general atmospheric corrosion resistance such as chemical and food processing equipment and marine applications.
- Tensile strength: 100,000 psi. minimum.
- Unified screw threads :UNC.
- Diameter: 5/16"-18.
- Length: 2-1/2".
$95.00
$0.95
$0.95
HEX CAP SCREW UNC STAINLESS 5/16"-18 X 3/4"
5634CSS
- Grade 18-8 stainless steel hex cap screws.
- Used in products that require general atmospheric corrosion resistance such as chemical and food processing equipment and marine applications.
- Tensile strength: 100,000 psi. minimum.
- Unified screw threads :UNC.
- Diameter: 5/16"-18.
- Length: 3/4".
$32.67
$0.3267
$0.3267
MACHINE SCREW HEX UNSLOTTED #10-32 X 1-1/2" STAINLESS
X1032X112HSS
- A straight shank fastener with external threads designed to go through a hole or nut that is pre-tapped to form a mating thread for the screw.
- Machine screws form a fastening superior in strength to spaced thread screws.
- Stainless steel machine screws are used in applications which require general atmospheric corrosion resistance.
- Used in food processing machinery and refrigeration equipment.
- Stainless is also superior to steel in withstanding some elevation in application operating temperature while maintaining its strength.
$60.00
$0.60
$0.60
MACHINE SCREW PHIL PAN HD #10-32 X 1-1/2" STAINLESS
X1032X112PSS
- A straight shank fastener with external threads designed to go through a hole or nut that is pre-tapped to form a mating thread for the screw.
- Machine screws form a fastening superior in strength to spaced thread screws.
- Stainless steel machine screws are used in applications which require general atmospheric corrosion resistance.
- Used in food processing machinery and refrigeration equipment.
- Stainless is also superior to steel in withstanding some elevation in application operating temperature while maintaining its strength.
- Made from 18-8 stainless
- Pan head Phillips.
- 10-32 diameter.
- Length of 1-1/2".
$46.57
$0.4657
$0.4657
SOCKET HEAD CAPSCREW UNC PLAIN #10-32 X 1-1/2"
X1032X112SHC
- Made from alloy steel.
- Cylindrical head with a flat chamfered top surface.
- Knurled cylindrical sides and hexagonal recess.
- Ideal for precision assembly work with close tolerances, and applications needing a well tooled appearance.
- Supplies greater tensile strength than equivalent sizes of grade 5 and grade 8 hex cap screws while requiring less surface area or counterbore since the fastener is internally wrenched.
- Plain black finish.
- Diameter: #10-32
- Length: 1-1/2"
$1.07
$0.2149
$0.2149
MACHINE SCREW PHIL PAN HD #10-32 X 1-1/4" STAINLESS
X1032X114PSS
- A straight shank fastener with external threads designed to go through a hole or nut that is pre-tapped to form a mating thread for the screw.
- Machine screws form a fastening superior in strength to spaced thread screws.
$37.40
$0.374
$0.374
MACHINE SCREW PHIL FLAT HD #10-32 X 1/2" STAINLESS
X1032X12FHPS
- A straight shank fastener with external threads designed to go through a hole or nut that is pre-tapped to form a mating thread for the screw.
- Machine screws form a fastening superior in strength to spaced thread screws.
- Stainless steel machine screws are used in applications which require general atmospheric corrosion resistance.
- Used in food processing machinery and refrigeration equipment.
- Stainless is also superior to steel in withstanding some elevation in application operating temperature while maintaining its strength.
$40.00
$0.40
$0.40
SOCKET HEAD CAPSCREW UNC PLAIN #10-32 X 1/2"
X1032X12SHC
- Made from alloy steel.
- Cylindrical head with a flat chamfered top surface.
- Knurled cylindrical sides and hexagonal recess.
- Ideal for precision assembly work with close tolerances, and applications needing a well tooled appearance.
- Supplies greater tensile strength than equivalent sizes of grade 5 and grade 8 hex cap screws while requiring less surface area or counterbore since the fastener is internally wrenched.
- Plain black finish.
- Diameter: #10-32
- Length: 1/2"
$25.92
$0.2592
$0.2592
